Compact and whisper-quiet spotlight for colored and white light
- 16 powerful LEDs 4 W SMD 3535 R/G/B/WW
segments controlled separately
- Additional frost filter provides a wide, soft and homogeneous light
- Color blend stepless; color change automatic; color fade automatic; Dimmer electronic; program speed adjustable
- Wash effect; Strobe effect
- 41 integrated show programs
- Direct color selection for 15 preset colors
- The device is cooled by passive convection cooling
- Control via stand-alone; Sound to light via Microphone; Master/slave function; IR remote control (not included); DMX; QuickDMX via USB (optional); W-DMX by wireless solution via USB (optional); CRMX by LumenRadio via USB (optional)
- Flicker-free
- With a beam angle of 20°
- With double bracket
- Monochrome 4 digit 7-segment LED display
- Mains input and output for power linking up to 8 units
- For application areas such as: Clubs/dancing school; Wedding/gala/events; Stage; theater; mobile djs / entertainer
- Silent operation
- Application possibility: Standing; suspended; on stand
- Preprogrammed in Light´J; Light Captain; EASY SHOW 1; EASY SHOW 2; EASY SHOW 3; Colorchief
Package contents
- 1 x device, 1 x user manual, 1 x power cord, 1 x diffusor cover
| Power supply: |
100-240 V AC, 50/60 Hz |
| Power consumption: |
70 W |
| IP classification: |
IP20 |
| Protection class: |
Protection class I |
| Power connection: |
Mains input via P-Con (blue), mounting version power supply cord with safety plug (provided) |
| Power output: |
P-Con (gray), mounting version |
| Fuse: |
5 x 20 mm, T 1,6 A Fuse replaceable |
| Battery: |
1 x Button cell 3.0 V CR2032 lithium manganese built-in |
| Lamp type: |
LED lamp |
| LED: |
16 x 4 W SMD 3535 R/G/B/WW |
| Flash rate: |
1 - 25 Hz |
| DMX channels: |
4; 6; 8; 16; 18; 20 |
| DMX input: |
1 x 3-pin XLR (M) mounting version |
| DMX output: |
1 x 3-pin XLR (F) mounting version Bypass |
| Cooling: |
Passive convection cooling |
| Control: |
Stand-alone; Sound to light via Microphone; Master/slave function; IR remote control (not included); DMX; QuickDMX via USB (optional); W-DMX by wireless solution via USB (optional); CRMX by LumenRadio via USB (optional) |
| Preprogrammed in: |
Light´J; Light Captain; EASY SHOW 1; EASY SHOW 2; EASY SHOW 3; Colorchief |
| Beam angle: |
20° |
| Beam angle (1/2 peak): |
20°
Frost filter 30° |
| Beam angle (1/10 peak): |
50°
Frost filter 80 |
| Housing color: |
Black |
| Attachment system: |
Double bracket |
| Display type: |
Monochrome 4 digit 7-segment LED display |
| Dimensions: |
Length: 33 cm
Width: 17 cm
Depth: 17 cm |
| Weight: |
2,52 kg |
| Noise classification: |
Class 0 (no noise at all) |
| Legal specifications |
| Special product: |
Not designed for household room illumination |
| Intended use: |
Show effect lighting |
| Shipping weight: |
3,05 kg
|
| Dimensions(LxWxH)
( Length × Width × Height ):
|
14,00 × 38,00 × 29,00 cm |
