Big sound in small package, mounting bracket included
- Real 250 W RMS with high-end sound quality
- Coaxial transducer for unmatched spatial coherence
- High efficiency for incredible SPL to size ratio
- HF compression driver with ketone polymere dome
- With panning and tilting mounting bracket for ceiling or wall installation in most varying angles
- Celto Acoustique driver
- For application areas such as: Theater; sports centres/gyms; Clubs/dancing school; restaurants, bars and hotels
Package contents
- 1 x top, 1 x mounting bracket, 1 x nut, 8 x washer, 1 x safety eyelet, 2 x screw, 1 x screw plug-in terminal
| Power: |
Rated: 300W AES
Program: 600W
Peak: 1200W |
| Frequency range: |
95 - 22000 Hz |
| Sensitivity: |
97 dB (1W/1m) |
| Max. SPL: |
128 dB |
| Dispersion angle: |
80° x 80° |
| Impedance: |
8 ohms |
| Attachment system: |
Panning and tilting mounting bracket for ceiling or wall installation in most varying angles |
| Connections: |
Input: speaker via screw terminal |
| Crossover frequency: |
Passive 1500 Hz
Recommended
In subwoofer combination
High-pass 90-130 Hz, 24db/oct with iFIX13S or iFIX17S subwoofer |
| Speaker: |
1 x woofer 10" with ferrit magnet
Diaphragmmaterial: PEEK (H.T. polymer)
Voice coil lows 2,5"
1 x Annular compression driver 1"
Voice coil annular 1,75" |
| Type of speaker: |
On-ceiling/on-wall speaker; Coaxial speaker |
| Type of construction: |
Closed Box |
| Use of brands: |
Celto Acoustique driver |
| Material: |
Birch multiplex, 15 mm, CNC made with tongue and grove assembly |
| Color: |
Black, textured coating, painted |
| Dimensions: |
Width: 30 cm
Depth: 30,4 cm
Height: 30 cm |
| Weight: |
12,85 kg |
| Shipping weight: |
14,00 kg
|
