Powerful A/D converter
- Converts analog input signals (0-12 V) into digital DMX output signals (8-bit or 16-bit)
- Supports a wide range of sensors, potentiometers, triggers and switches
- Creative and interactive projects can be easily put into practice thanks to sensors for light, temperature, movements etc.
- Works as a connecting tool between such equipment and a receiver usually processing the incoming signals
- Can be connected to building automation systems
- Transmits data over Ethernet network (Art-Net / ACN)
- Can also be used as Madrix USB interface with Madrix-5 software
- 2 main 6-pin connectors with 4 individual pins each as well as GND and V+ for direct connection of equipment, 8 inputs in total
- 2 Ethernet ports allow for separate network connections and linearly daisy-chaining several devices without an additional network switch
- Various options for connection and power supply for the device itself as well as connected equipment
- Versatile output through adjustable inputs: Each input individually can be defined as analog or digital input, counter or other useful types
- Works great with the Madrix software with quick and easy installation (sold separately)
- Complies with the official Art-Net and Streaming ACN specifications and can be used as regular Art-Net unit with other consoles, controllers, or software solutions
- 8 status LEDs which can be turned off
- Built-in web tool for on-device configuration
- Can be mounted on 35-mm DIN rails or walls via the provided wall-mount brackets
- Non-conductive enclosure with IP20 and UL94 V-O flammability rating
- Fanless, low-energy design
- Ready within seconds after startup
- Recommended for any small or large installation
- Multiple devices can be used together without problems
- The firmware is upgradable for future features
- Software user manual available in English and German
- Made in Germany
- User manuals also available at help.madrix.com
- Made in Germany
| Shipping weight: |
0,58 kg
|
| Dimensions(LxWxH)
( Length × Width × Height ):
|
8,00 × 22,50 × 16,50 cm |
