3in1 LED bar with RGBW beam effects, color animations and stroboscope
- Stepless color blend, running light, preset colors, dimmer and strobe effect
- Electronic dimmer
- Mains input and output for power linking up to 8 units
- Background color macros controllable via DMX
- 14 powerful LEDs 5 W high-power 4in1 QCL RGBW (homogenous color mix)
- 120 powerful LEDs SMD 5050 3in1 TCL RGB (homogenous color mix)
- 180 powerful LEDs SMD 5730 cold white (CW)
- 7 integrated Showprograms
- Direct color selection for 38-42 preset colors
- Can be operated in 9; 11; 17; 19 CH mode
- The device is cooled by passive convection cooling
- Controlling by stand-alone; Sound to light via Microphone; Master/slave function; DMX
- Flicker-free
- With a beam angle of 10°
- With Mounting bracket
- 4 digits 7-segment LED display
Package contents
- 1 x light effect, 1 x user manual, 1 x power cord
| Power supply: |
100-240 V AC, 50/60 Hz |
| Power consumption: |
120 W |
| IP classification: |
IP20 |
| Protection class: |
Protection class I |
| Power connection: |
Mains input via P-Con (blue), mounting version power supply cord with safety plug (provided) |
| Power output: |
P-Con (gray), mounting version |
| Lamp type: |
LED lamp |
| LED: |
14 x 5 W high-power 4in1 QCL RGBW (homogenous color mix)
120 x SMD 5050 3in1 TCL RGB (homogenous color mix)
180 x SMD 5730 cold white (CW) |
| Flash rate: |
0 - 20 Hz |
| DMX channels: |
9; 11; 17; 19 |
| DMX input: |
3-pin XLR (M) mounting version |
| DMX output: |
3-pin XLR (F) mounting version |
| Cooling: |
Passive convection cooling |
| Control: |
Stand-alone; Sound to light via Microphone; Master/slave function; DMX |
| Beam angle: |
10° |
| Beam angle (1/2 peak): |
Beam 10°
Ambient light 120° |
| Beam angle (1/10 peak): |
Beam 20° |
| Housing color: |
Black |
| Attachment system: |
2x Mounting bracket |
| Display type: |
4 digits 7-segment LED display |
| Dimensions: |
Length: 1 m
Depth: 6,7 cm
Height: 12,0 cm |
| Weight: |
3,96 kg |
| Legal specifications |
| Special product: |
Not designed for household room illumination |
| Intended use: |
Show effect lighting |
| Shipping weight: |
4,48 kg
|
| Dimensions(LxWxH)
( Length × Width × Height ):
|
16,00 × 105,00 × 12,50 cm |
