LED beam effect with RGBW color mixing and 8 RGB hypno rings
- 8 powerful LEDs 10 W SMD 4in1 QCL RGBW
- 96 powerful LEDs 0,2 W SMD 5050 3in1 TCL RGB
- Dimmer electronic; color fade; color change; color blend; Rotation speed; Rotation direction
- Multi beam effect
- 2 integrated show programs
- The device is cooled by cooling fan
- Control via stand-alone; DMX; QuickDMX via USB (optional); W-DMX by wireless solution via USB (optional); CRMX by LumenRadio via USB (optional); Sound to light via Microphone; Master/slave function
- Fuzzy sound control: program continues automatically during periods without music or bass-beat
- Flicker-free
- 4 digit 7-segment LED display
- With Omega bracket; with Holder for wall mounting
- Application possibility: Standing; suspended
- Preprogrammed in Light Captain; Colorchief
- For application areas such as: Clubs/dancing school; Wedding/gala/events; Party room; mobile djs / entertainer; restaurants, bars and hotels
Package contents
- 1 x device, 1 x user manual, 1 x power cord, 2 x omega bracket, 2 x screw
| Power supply: |
100-240 V AC, 50/60 Hz |
| Power consumption: |
75 W |
| IP classification: |
IP20 |
| Protection class: |
Protection class I |
| Power connection: |
Mains input via IEC connector (M) mounting version power supply cord with safety plug |
| Fuse: |
5 x 20 mm, T 3,15 A Fuse replaceable |
| Lamp type: |
LED lamp |
| LED: |
8 x 10 W SMD 4in1 QCL RGBW
96 x 0,2 W SMD 5050 3in1 TCL RGB |
| Max. TILT movement: |
360° Positioning infinity |
| Max. PAN movement: |
540° |
| Flash rate: |
0 - 20 Hz |
| DMX channels: |
16 |
| DMX input: |
3-pin XLR (M) mounting version |
| DMX output: |
3-pin XLR (F) mounting version |
| Cooling: |
Cooling fan |
| Control: |
Stand-alone; DMX; QuickDMX via USB (optional); W-DMX by wireless solution via USB (optional); CRMX by LumenRadio via USB (optional); Sound to light via Microphone; Master/slave function |
| Preprogrammed in: |
Light Captain; Colorchief |
| Housing color: |
Black |
| Attachment system: |
Omega bracket
Holder for wall mounting |
| Display type: |
4 digit 7-segment LED display |
| Diameter mounting holes: |
4 x Ø5mm |
| Material: |
Plastic |
| Dimensions: |
Width: 27,0 cm
Depth: 21,0 cm
Height: 35,5 cm |
| Weight: |
4,50 kg |
| Noise classification: |
Class 2 (slight noise) |
| Legal specifications |
| Special product: |
Not designed for household room illumination |
| Intended use: |
Show effect lighting |
| Shipping weight: |
5,10 kg
|
| Dimensions(LxWxH)
( Length × Width × Height ):
|
42,00 × 32,00 × 25,00 cm |
Product safety information
Manufacturer information:
Steinigke Showtechnic GmbH
Andreas-Bauer-Str. 5
97297 Waldbüttelbrunn, Deutschland
https://www.steinigke.de/support
